Reticulate is an open source R package that provides a python interface to your R session. This allows users to leverage the power of R and Python in a single workflow. Before you start using reticulate, it’s important that you first configure your R project to accommodate Python code and packages. reticulate does provide some built in functions to help with this, but for this stepping stone, we’ll do this manually with the help of venv.

Similar to how you manage R environment and packages using R Projects and renv, we need to set up a similar environment for Python.

Step 1: Create an R Project

An R project is your project’s home directory. It’s always a good idea to keep projects isolated from other projects to avoid conflicts. There are multiple ways to create R projects:

  • File –> New Project
  • Click the Create a New Project icon in the top left of the RStudio IDE.
  • Select New Project from the dropdown menu in the top right corner of the RStudio IDE.
  • Use the create_project() function from the usethis package

Step 2: Create a new Python virtual environment

A virtual environment will ensure that any python packages you install remain isolated to this R project. To do this, we will use the venv python module:

  1. In the RStudio terminal, and within the same R project home directory, create a virtual env: python -m venv .venv
  2. Activate the virtual environment: source .venv/bin/activate
  3. You should now see a (.venv) in the terminal prompt letting you know that you are inside the virtual environment.

Step 3: Point reticulate to your Python virtual environment

  1. Make sure the RETICULATE_PYTHON variable is set to “.venv/bin/activate” in the project’s .Renviron file.
  2. Restart R.
  3. Confirm that reticulate will now use Python from within your virtual environment by running: Sys.getenv("RETICULATE_PYTHON"). The output should read: .venv/bin/python.

Additional notes

  • If your using Quarto + reticulate, then make sure to set the engine to use knitr in the yaml.

Example Quarto Doc using R + Python

---
title: "R + Python"
author: "Ryan Johnson"
format: html
engine: knitr
editor: visual
---
library(reticulate)

Below is the code for a line plot using Python.

#| label: python-plot

import numpy as np
import matplotlib.pyplot as plt

# Data for plotting
t = np.arange(0.0, 2.0, 0.01)
s = 1 + np.sin(2 * np.pi * t)

fig, ax = plt.subplots()
ax.plot(t, s)

ax.set(xlabel='X', ylabel='Y',
       title='A Plot using Python')
ax.grid()

plt.show()

Below is the code for a line plot in R, using the same data as the python plot.

#| label: r-plot
#| message: false

library(ggplot2)
library(dplyr)

# Read python data into R using py$
r_data <- tibble(X = py$t, Y = py$s)

ggplot(data = r_data, aes(x = X, y = Y)) +
  geom_line(color = "#398AD7", size = 2) +
  theme_minimal() +
  labs(title = "A Plot using R")
